Supercharging GitHub Actions with Job Summaries

You can now output and group custom Markdown content on the Actions run summary page.

KP

Konrad PabjanGitHub

·May 9, 2022

Supercharging GitHub Actions with Job Summaries

Job Summaries bring Markdown to GitHub Actions run pages

GitHub Actions now supports Job Summaries, letting jobs write custom Markdown content directly to the run summary page. The feature uses the same rendering engine that powers pull requests, issues, and README files, so anything you can format there will display correctly in the Actions UI.

Common uses include aggregating test results, generating build reports, or surfacing custom output that doesn't belong in the raw logs. Job Summaries complement existing annotations, which remain the right tool for highlighting errors and warnings.

How to create a summary

Writing a summary requires only one step: append Markdown to the new $GITHUB_STEP_SUMMARY environment variable. Any content added to that file appears on the run summary page.

steps:
  - name: Adding markdown
    run: echo '### Hello world! 🚀' >> $GITHUB_STEP_SUMMARY

The mechanism mirrors how $GITHUB_ENV works for defining environment variables, so it should feel familiar to Actions authors.

For convenience, the @actions/core npm package includes a helper utility for generating summaries. It supports appending individual lines or larger Markdown blocks, and includes a method for building tables, which is expected to be a frequent use case.

import * as core from '@actions/core'
  await core.summary
  .addHeading('Test Results')
  .addCodeBlock(generateTestResults(), "js")
  .addTable([
    [{data: 'File', header: true}, {data: 'Result', header: true}],
    ['foo.js', 'Pass ✅'],
    ['bar.js', 'Fail ❌'],
    ['test.js', 'Pass ✅']
  ])
  .addLink('View staging deployment!', 'https://github.com')
  .write()

Closing a long-standing feature gap

Previously, user-generated content from Actions was limited to logs and annotations. Logs are poorly suited for grouping large amounts of information, and annotations are designed for highlighting specific problems rather than displaying rich output like test summaries or reports.

Workarounds existed but were not practical. Some teams manually created check runs via the API using the GITHUB_TOKEN provided during a run, which added overhead and reduced productivity. Job Summaries eliminate that need by giving users a native path for structured output directly on the run summary.

What the Markdown renderer supports

Job Summaries accept GitHub Flavored Markdown, the same syntax used across pull requests and issues. This gives users access to a wide range of formatting options, including tables, code blocks, links, and embedded content.

Examples of what the renderer can handle:
