How To Build A Node.js API For Ethereum Blockchain — Smashing Magazine

Create an .env file with touch .env to store the MongoDB connection URI. The dotenv package loads these variables into the Node.js process environment. Never commit the .env file to public repositories, as it may contain passwords and private data.

Next, add build and development scripts to package.json. The default generated file looks like this:

{
  "name": "test",
  "version": "1.0.0",
  "description": "",
  "main": "server.js",
  "scripts": {
    "test": "echo \"Error: no test specified\" && exit 1"
  },
  "keywords": [],
  "author": "",
  "license": "ISC",
  "dependencies": {
    "express": "^4.17.1",
    "socket.io": "^2.3.0",
    "truffle-contract": "^4.0.31",
    "web3": "^1.3.0"
  }
}

Add a start script that runs the server with nodemon (so changes restart the server automatically) and a build script that uses node directly:

{
  "name": "test",
  "version": "1.0.0",
  "description": "",
  "main": "server.js",
  "scripts": {
    "test": "echo \"Error: no test specified\" && exit 1",
    "start": "nodemon server.js",
    "build": "node server.js"

  },
  "keywords": [],
  "author": "",
  "license": "ISC",
  "dependencies": {
    "express": "^4.17.1",
    "socket.io": "^2.3.0",
    "truffle-contract": "^4.0.31",
    "web3": "^1.3.0"
  }
}

Initialize Truffle in the project folder using the globally installed package:

$ truffle init

Now open server.js and set up the application skeleton. The example below keeps the server clean by moving routes and business logic to separate files:

require('dotenv').config();
const express= require('express')
const app =express()
const routes = require('./routes')
const Web3 = require('web3');
const mongodb = require('mongodb').MongoClient
const contract = require('truffle-contract');
app.use(express.json())

mongodb.connect(process.env.DB,{ useUnifiedTopology: true },(err,client)=>{
    const db =client.db('Cluster0')
    //home
    routes(app,db)
    app.listen(process.env.PORT || 8082, () => {
        console.log('listening on port 8082');
     })
})

This file imports needed libraries with require, enables JSON in the API via app.use, connects to MongoDB using the URI from the environment, and selects the Cluster0 database. The routes function imported from routes.js is then invoked, and the server listens on port 8082.

Five API Endpoints

The API exposes five endpoints for users:

1. Registration — registers a user by email. To keep the tutorial focused, we skip password hashing and security, since the goal is simply user identification.


   POST /register
   Requirements: email


2. Login — authenticates a user by email.


   POST /login
   Requirements: email


3. Upload — accepts music file data. The frontend converts MP3/WAV files to an audio buffer and sends that buffer to the API.


   POST /upload
   Requirements: name, title of music, music file buffer or URL stored


4. Access — provides the music buffer to any registered user who requests it, logging who accessed it.


   GET /access/{email}/{id}
   Requirements: email, id


5. Library — returns the full music library to a registered user.


   GET /access/{email}
   Requirements: email


Write these route functions in routes.js, using MongoDB operations for storage and retrieval. Make sure the route function is exported at the end of the file so it can be imported elsewhere:

const shortid = require('short-id')
function routes(app, db){
    app.post('/register', (req,res)=>{
        let email = req.body.email
        let idd = shortid.generate()
        if(email){
            db.findOne({email}, (err, doc)=>{
                if(doc){
                    res.status(400).json({"status":"Failed", "reason":"Already registered"})
                }else{
                    db.insertOne({email})
                    res.json({"status":"success","id":idd})
                }
            })
        }else{
            res.status(400).json({"status":"Failed", "reason":"wrong input"})
        }
    })
    app.post('/login', (req,res)=>{
        let email = req.body.email
        if(email){
            db.findOne({email}, (err, doc)=>{
                if(doc){
                    res.json({"status":"success","id":doc.id})
                }else{
                    res.status(400).json({"status":"Failed", "reason":"Not recognised"})
                }
            })
        }else{
            res.status(400).json({"status":"Failed", "reason":"wrong input"})
        }
    })
    app.post('/upload', (req,res)=>{
        let buffer = req.body.buffer
        let name = req.body.name
        let title = req.body.title
        if(buffer && title){

        }else{
            res.status(400).json({"status":"Failed", "reason":"wrong input"})
        }
    })
    app.get('/access/:email/:id', (req,res)=>{
        if(req.params.id && req.params.email){

        }else{
            res.status(400).json({"status":"Failed", "reason":"wrong input"})
        }
    })
}
module.exports = routes

Inside the exported route function, the app and db parameters are used to define endpoint functions. The four standard HTTP operations form the basis:

• get — read records
• post — create records
• put — update records
• delete — delete records

This example uses post for registration, login, and upload, and get for data access. The database operations are visible in the register route (db.createa) and login route (db.findOne). All operations target a named collection specified with db.collection. For a deeper reference on MongoDB shell operations, see the mongo Shell Methods documentation.

Writing a Solidity Contract

Smart contracts on Ethereum are written in Solidity, a language with JavaScript-like syntax. For this project, we store the music file’s IPFS address on-chain rather than the file itself, which keeps transaction costs low and preserves the integrity of the stored reference.

Create a new file Inbox.sol in the contracts folder. Inside it, define a contract named Inbox with structures, events, and modifiers that will be used by an ipfsInbox object. After initializing the contract via its constructor, define three functions: sendIPFS, where the user supplies an identifier and the hash address to be permanently recorded; getHash, which returns the stored hash for a given identifier; and checkInbox, which is included primarily for testing results.

pragma solidity ^0.5.0;

contract Inbox{
    //Structure
    mapping (string=>string) public ipfsInbox;
    //Events
    event ipfsSent(string _ipfsHash, string _address);
    event inboxResponse(string response);
    //Modifiers
    modifier notFull (string memory _string) {
    bytes memory stringTest = bytes(_string);
    require(stringTest.length==0);
    _;
    }
    // An empty constructor that creates an instance of the conteact
    constructor() public{}
    //takes in receiver's address and IPFS hash. Places the IPFSadress in the receiver's inbox
    function sendIPFS(string memory _address, string memory _ipfsHash) notFull(ipfsInbox[_address]) public{
        ipfsInbox[_address] = _ipfsHash;
        emit ipfsSent(_ipfsHash, _address);
    }
    //retrieves hash
    function getHash(string memory _address) public view returns(string memory) {
        string memory ipfs_hash=ipfsInbox[_address];
         //emit inboxResponse(ipfs_hash);
        return ipfs_hash;
    }
}

Testing the contract is easiest in the Remix IDE, where you can paste, run, and debug the Solidity code interactively. Once the logic is verified there, move on to a local compilation and migration with Truffle.

Compiling and Migrating Locally

Start by installing the blockchain emulator ganache-cli in the same directory:

$ npm install ganache-cli -g

Keep that terminal running and open a second one for the next steps. The emulator provides a local Ethereum node for contract deployment and testing during development.

Next, configure Truffle. In the truffle.js (Linux/Mac) or truffle-config.js (Windows) file, add the build folder path where compiled JSON artifacts will be placed and specify the network to use for migration:

const path = require("path");
module.exports = {
  // to customize your Truffle configuration!
  contracts_build_directory: path.join(__dirname, "/build"),
  networks: {
    development: {
      host: "127.0.0.1",
      port: 8545,
      network_id: "*" //Match any network id
    }
  }
};

In the migrations folder, create 2_migrate_inbox.js. This file imports the compiled contract and uses Truffle’s deployer function to deploy it automatically during migration:

var IPFSInbox = artifacts.require("./Inbox.sol");
module.exports = function(deployer) {
    deployer.deploy(IPFSInbox);
};

Compile the contracts with:

$ truffle compile

A successful compilation prints messages that look like this:

> Compiled successfully using:
    - solc: 0.5.16+commit.9c3226ce.Emscripten.clang

Execute the migration with:

$ truffle migrate

A completed migration confirms the contract is deployed to the local emulator. Verify this from the output tail:

Summary
=======
> Total deployments:   1
> Final cost:          0.00973432 ETH

Now write a test file to validate the contract behavior. Place InboxTest.js in the test folder:

const IPFSInbox = artifacts.require("./Inbox.sol")
contract("IPFSInbox", accounts =>{
    it("emit event when you send a ipfs address", async()=>{
        //ait for the contract
        const ipfsInbox = await IPFSInbox.deployed()

        //set a variable to false and get event listener
        eventEmitted = false
        //var event = ()
        await ipfsInbox.ipfsSent((err,res)=>{
            eventEmitted=true
        })
        //call the contract function  which sends the ipfs address
        await ipfsInbox.sendIPFS(accounts[1], "sampleAddress", {from: accounts[0]})
        assert.equal(eventEmitted, true, "sending an IPFS request does not emit an event")
    })
})

Run the test suite:

$ truffle test

The test runner executes the contract code and reports which tests passed or failed, for this tutorial expecting the following result:

$ truffle test
Using network 'development'.
Compiling your contracts...
===========================
> Compiling .\contracts\Inbox.sol
> Artifacts written to C:\Users\Ademola\AppData\Local\Temp\test--2508-n0vZ513BXz4N
> Compiled successfully using:
   — solc: 0.5.16+commit.9c3226ce.Emscripten.clang

  Contract: IPFSInbox
    √ emit event when you send an ipfs address (373ms)

  1 passing (612ms)

Connecting Web3 to the API

Front-end-only decentralized apps are common, but backend integration is necessary when incorporating third-party services or building a CMS on blockchain. Web3 is the bridge that lets Node.js talk to either a local Ethereum node (like ganache-cli) or a remote one (e.g., Ropsten or Rinkeby testnets). This tutorial sticks with the local node, but the same pattern applies to a remote deployment by storing the contract address in a .env file and referencing it during setup.

Update server.js to initialize a Web3 instance on port 8545 if one doesn’t already exist, then load the migrated contract JSON and instantiate it with truffle-contract, setting its provider to the Web3 instance provider:

require('dotenv').config();
const express= require('express')
const app =express()
const routes = require('./routes')
const Web3 = require('web3');
const mongodb = require('mongodb').MongoClient
const contract = require('truffle-contract');
const artifacts = require('./build/Inbox.json');
app.use(express.json())
if (typeof web3 !== 'undefined') {
    var web3 = new Web3(web3.currentProvider)
  } else {
    var web3 = new Web3(new Web3.providers.HttpProvider('https://localhost:8545'))
}
const LMS = contract(artifacts)
LMS.setProvider(web3.currentProvider)
mongodb.connect(process.env.DB,{ useUnifiedTopology: true }, async(err,client)=>{
    const db =client.db('Cluster0')
    const accounts = await web3.eth.getAccounts();
    const lms = await LMS.deployed();
    //const lms = LMS.at(contract_address) for remote nodes deployed on ropsten or rinkeby
    routes(app,db, lms, accounts)
    app.listen(process.env.PORT || 8082, () => {
       console.log('listening on port '+ (process.env.PORT || 8082));
     })
})

Retrieve the accounts with web3.eth.getAccounts. In development, call the deployed function against ganache-cli to get a contract address. For a remote node, pass that address as an argument via an equivalent function call (shown as a comment in the code). Finally, pass the app, database, contract instance, and accounts to the routes function and listen for requests on port 8082.

The router follows the same pattern. Import short-id and ipfs-http-client, then initialize IPFS with the Infura backend URL ipfs.infura.io on port 5001. The interface accepts audio buffers and returns file addresses:

const shortid = require('short-id')
const IPFS =require('ipfs-api');
const ipfs = IPFS({ host: 'ipfs.infura.io',
    port: 5001,protocol: 'https' });

function routes(app, dbe, lms, accounts){
    let db= dbe.collection('music-users')
    let music = dbe.collection('music-store')
    app.post('/register', (req,res)=>{
        let email = req.body.email
        let idd = shortid.generate()
        if(email){
            db.findOne({email}, (err, doc)=>{
                if(doc){
                    res.status(400).json({"status":"Failed", "reason":"Already registered"})
                }else{
                    db.insertOne({email})
                    res.json({"status":"success","id":idd})
                }
            })
        }else{
            res.status(400).json({"status":"Failed", "reason":"wrong input"})
        }
    })

    app.post('/login', (req,res)=>{
        let email = req.body.email
        if(email){
            db.findOne({email}, (err, doc)=>{
                if(doc){
                    res.json({"status":"success","id":doc.id})
                }else{
                    res.status(400).json({"status":"Failed", "reason":"Not recognised"})
                }
            })
        }else{
            res.status(400).json({"status":"Failed", "reason":"wrong input"})
        }
    })
    app.post('/upload', async (req,res)=>{
        let buffer = req.body.buffer
        let name = req.body.name
        let title = req.body.title
        let id = shortid.generate() + shortid.generate()
        if(buffer && title){
            let ipfsHash = await ipfs.add(buffer)
            let hash = ipfsHash[0].hash
            lms.sendIPFS(id, hash, {from: accounts[0]})
            .then((_hash, _address)=>{
                music.insertOne({id,hash, title,name})
                res.json({"status":"success", id})
            })
            .catch(err=>{
                res.status(500).json({"status":"Failed", "reason":"Upload error occured"})
            })
        }else{
            res.status(400).json({"status":"Failed", "reason":"wrong input"})
        }
    })
    app.get('/access/:email', (req,res)=>{
        if(req.params.email){
            db.findOne({email: req.body.email}, (err,doc)=>{
                if(doc){
                    let data = music.find().toArray()
                    res.json({"status":"success", data})
                }
            })
        }else{
            res.status(400).json({"status":"Failed", "reason":"wrong input"})
        }
    })
    app.get('/access/:email/:id', (req,res)=>{
      let id = req.params.id
        if(req.params.id && req.params.email){
            db.findOne({email:req.body.email},(err,doc)=>{
                if(doc){
                    lms.getHash(id, {from: accounts[0]})
                    .then(async(hash)=>{
                        let data = await ipfs.files.get(hash)
                        res.json({"status":"success", data: data.content})
                    })
                }else{
                    res.status(400).json({"status":"Failed", "reason":"wrong input"})
                }
            })
        }else{
            res.status(400).json({"status":"Failed", "reason":"wrong input"})
        }
    })
}

module.exports = routes

In the upload route, push the audio buffer to IPFS, get back its hash, generate a unique identifier, and record that hash on-chain via the sendIPFS contract method. Then store the remaining metadata in MongoDB. The download route authenticates the user by email, retrieves the IPFS hash using the identifier from the request, and streams the audio buffer back.

From Semi-dApp to Production

The completed stack is a semi-dApp, since on-chain storage is limited to content addresses while the bulk of the data stays in a centralized database. That separation provides cheaper storage and quicker lookups than a fully on-chain model, while still giving artists a direct distribution channel without royalties going to intermediaries. Music platforms built on this pattern include OPUS, Musicoin, Audius, and Resonate.

After starting the server with either npm run start or npm run build, test every endpoint from the browser or Postman. Add unit and integration tests early; they prevent regressions and lock in behavior before cloud deployment to Heroku, GCP, or AWS. The reference implementation is available on GitHub; note that the .env containing the MongoDB URI is excluded for security.

Learning Resources

• “How to Build Ethereum Dapp with React.js: Complete Step-By-Step Guide” — Gregory McCubbin
• “Ethereum + IPFS + React DApp Tutorial Pt. 1” — Alexander Ma
• “Ethereum Development with Go” — Miguel Mota
• “Create your first Ethereum dAPP with Web3 and Vue.JS (Part 1)” — Nico Vergauwen
• “Deploy a Smart Contract on Ethereum with Python, Truffle and web3py” — Gabriel Saldanha
• “How To Build A Blockchain App With Ethereum, Web3.js & Solidity Smart Contracts” — Gregory McCubbin
• “How To Build A Simple Cryptocurrency Blockchain In Node.js” — Alfrick Opidi
• “Learn about Ethereum” — Ethereum official site
